German Genetics, Chinese Intelligence, Made for Harsh Industrial Conveying
In the global industrial conveying field, ContiTech is a name that carries the spirit of 100 years of German industry. As a conveyor solution specialist of Continental, ContiTech's steel cord conveyor belts are renowned worldwide for their German engineering, long service life and ultimate safety. Base on many years working experience with Contitech, what we want to introduce to you is not only the honor of this brand - it is the brand-new value of integrating premium quality and Chinese speed, which has been rooted in China for more than 20 years.
Brand and Product Positioning: German Engineering, Global Benchmark
ContiTech's steel cord Rubber conveyor belts are high-strength conveying solutions tailored for heavy industrial scenarios such as mines, power plants, terminals, cement and chemicals. Its core advantages stem from the extreme pursuit of every technical detail.
|
Core Technology and Quality Advantages |
||
|
Technology Dimensions |
ContiTech Standards |
Industry Values |
|
Wire Rope Construction |
Highly galvanized open wire rope with high elasticity and low elongation |
Higher splice efficiency and corrosion protection |
|
High Tensile Strength |
Tensile Strength Up to ST10,000 (10,000 N/mm) |
For extreme conditions of ultra-long hauling distances and ultra-high lifting |
|
Elongation |
≤ 0.25% at rated tension |
Significantly reduced tensioning strokes and reduced investment costs |
|
Joint life as the belt |
Same life as tested by DIN 22131 Dynamic joints |
Reduced downtime for maintenance and tons of transportation costs |
|
Cover adhesion |
Excellent adhesion between cover and core adhesive |
Excellent impact and tear resistance |
|
Safety standards |
Complies with ISO/DIN global standards for flame retardancy and antistatic protection |
Dual safety for underground mines and open-air operations |
In the past, high-end steel cord conveyor belts mainly relied on imports, and customers had to go through a long waiting period. ContiTech has long completed its strategic layout in China – our factory serves as the localized production base, which perfectly integrates the technical specifications of the German headquarter with the manufacturing efficiency in China.
"What is the difference between those made in China and those made in Germany?"
-- This is the most common question asked by our customers. And our answer is: "There is no difference."
This confidence comes from a set of strict global management system: from the access audit of raw material suppliers, to the precision calibration of production equipment, to the full performance test of the final product, the Chinese factory and the German headquarters base implement the same set of technical specifications. Localization is not about lowering standards, but about making them more efficient.
Comparison of Differentiation with Other International Brands of Conveyor Belt
In the global rubber conveyor belt field, ContiTech, Fenner Dunlop, Bridgestone and Yokohama are known as the "four kings". However, in the increasingly competitive international market, ContiTech has formed a unique differentiation advantage by virtue of its deep localization, Chinese speed and years of service experience.
For all our end users who pursue German quality but are not willing to bear the import premium and long delivery time, ContiTech we introduced is the only international first-tier brand that can satisfy the four demands of "quality + price + delivery + service" at the same time.
Years of experience in cooperating with first-tier brands has given us the opportunity to have in-depth exchanges and cooperation with China's high-end rubber conveyor belt brands, giving us the ability to provide China's high-end conveyor belt brands that are adapted to the increasingly complex international demands and more competitive.
Solutions for Five Major Industry Applications
Mining (coal, copper, iron ore, gold)
Challenges: Restricted underground space, flammable and explosive environments, large ore impacts, long lifting distances.
Our Solutions:
● K-rated flame retardant: DIN 22103/ISO 340 compliant, preferred for safety in underground mines.
● High impact design: Cover and core are tightly bonded to cope with sharp ore impacts.
● Ultra-low elongation: 0.25% elongation for kilometers of mainline transportation.
● Typical applications: Coal main roadway transportation, long distance transportation from copper open pit to processing plant.
Power plants
Challenges: Continuous 24-hour operation, fluctuating coal flows, dusty environments, high reliability requirements.
Our Solutions:
● High strength wire rope cores: ST2000-ST5400 for coal flow impacts.
● Low rolling resistance compounds: Reduce energy consumption and meet energy saving requirements of power plants.
● Tear-resistant optional: Transverse reinforcement with tear-resistant layer for continuous operation.
● Typical applications: Coal conveyor systems in thermal power plants, fuel transportation in biomass power plants.
Port Terminals
Challenges: Corrosive open-air environments, tidal influences, continuous loading and unloading operations, high cost of emergency breakdowns.
Our Solutions:
● Corrosion-resistant design: Galvanized wire rope + corrosion-resistant cover rubber.
● Extra Long Single Reel: Reduced splices for long distance transportation in terminals.
● Rapid response service: 2-hour response circle in coastal port cities.
● Typical Applications: Coal/Ore Terminal Ship Loaders, Ship Unloader Conveyor Lines, Stacker Reclaimers.
Cement Industry
Challenges: High temperature clinker, sharp limestone, continuous heavy loads, dusty environments.
Our Solutions:
● Heat-resistant cover rubber: Customized to withstand high temperatures above 120°C.
● High abrasion resistance: DIN W/X rated overlay with abrasion ≤ 90mm³.
● Impact resistant design: To cope with large limestone impacts.
● Typical applications: Long-distance transportation from limestone mines to cement plants, clinker conveying lines.
Chemical industry
Challenges: Corrosive materials, oily environments, fire and explosion protection requirements.
Our Solutions:
● Oil/chemical resistant overlay adhesive: Special formulation design.
● Flame retardant and anti-static: Conforms to ISO 284 anti-static standard.
● Customized protection: Adaptation of adhesive formulations to media properties.
● Typical applications: Phosphate ore transportation, fertilizer raw material transportation, chemical plant raw material conveying line.
Customer Value: More Than a Product, it is a Whole Life Cycle Service
By choosing our Alumina Technology with Contitech brand steel cord rubber conveyor belt, you not only get a conveyor belt, but also a whole set of value guarantee through the whole life cycle.
